Intelligent Input/Output Module (250V AC) SA4700-103APO
Intelligent Input/Output Module (250V AC) SA4700-103APO - Image 2

Intelligent Input/Output Module (250V AC) SA4700-103APO

Category:

Description

SA4700-103APO

The Intelligent Input/Output Module is used to monitor two single pole, volt free contact inputs and control mains switching relay output contacts.

  • EN 54-17 & EN 54-18 Certified
  • Two input channels
  • Meets BS 7273-4 failsafe requirements
  • Ergonomic design for ease of wiring and faster installation
  • Suitable for semi flush or surface mounting
  • XP95, Discovery and CoreProtocol compatible

Additional Information

General
Warranty  :  10 year
Mechanical
Colour  :  White
Weight  :  301g
Product length  :  60mm
Product width  :  150mm
Product depth  :  90mm
Product length  :  2.36in
Product width :  5.91in
Product depth  :  3.54in
Conformance
Approvals
FG

LPCB

SBSC

BOSEC

VdS

CPR


Environmental
Humidity  :  0% to 95% (no condensation or icing)
Humidity Note  :  no condensation or icing
Humidity (max)  :  95% RH
Humidity (min)  :  0% RH
Operating temperature  :  -40 to 70°C
Operating temperature (max)  :  70°C
Operating temperature (min)  :  -40°C
IP rating Value  :  IP54
Operating temperature  :  -40 to 158°F
Operating temperature (max)  :  158°F
Operating temperature (min)  :  -40°F
